Offroad Industries BDS 3" Lift Kit FOX Performance Elite Chevrolet Silverado 2500HD (20-26)

BDS 3 Inch Lift Kit | FOX Performance Elite | Chevy Silverado 2500HD (20-26)
Engineered for the Chevy Silverado 2500HD (2020-2026), this BDS 3 inch lift kit combines proven suspension geometry with FOX Performance Elite 2.5 dampers to deliver superior articulation and ride quality. The system maintains composure across demanding terrain whilst preserving on-road stability, making it ideal for both remote exploration and daily driving. Featuring a straightforward bolt-on installation, you'll minimise downtime and get back to the track quickly. Built to handle Australia's diverse conditions, this suspension upgrade provides the clearance and control serious off-road enthusiasts demand.

Up front the lift kit includes FOX 2.5 Performance Elite reservoir shocks and heavy duty tubular upper control arms for increased strength. Along with the control arms, a pair of indexed cast steel torsion bar keys are supplied upfront to lift the vehicle and a small differential relocation kit is supplied to correct CV axle operating angles without affecting ground clearance. To eliminate sway bar interference, a pair of sway bar relocation brackets is used which maintains proper operating angle.

In the rear, a 2" block and u-bolt kit is used to create a level to slightly tail high stance when unloaded. Rounding out these kits are a pair of specially tuned FOX 2.5 Performance Elite reservoir shocks ready to soak up the terrain.

FOX Performance Elite
Experience uncompromising performance with FOX 2.5 Performance Elite shocks, purpose-built for your Chevy Silverado 2500HD. These race-proven shocks arrive pre-tuned and ready to bolt on, delivering superior comfort whether you're cruising highways or attacking rough terrain. The remote reservoir design maximises fluid capacity, keeping your suspension cool during aggressive driving and extended adventures. Fine-tune your ride with the innovative DSC adjuster—simply twist the knobs to access 10 low-speed and 12 high-speed compression settings, giving you precise control tailored to any condition. Black anodised aluminium construction enhances cooling efficiency while adding durability that withstands the harshest outback demands.

HD Upper Control Arms
Built for strength, performance and increased travel, these upper control arms are ready to bolt-in with most levelled/lifted trucks. They use 1.5" OD x .120-wall tubular construction with an indexed ball joint cup to correct the ball joint positioning allowing additional down travel and camber adjustment. At the frame mounting ends are durometer-specific rubber bushings for maintenance-free operation while at the other end a quality greaseable ball joints for smooth, quiet operation and superior durability. Arms are finished in a durable black powder coat with a billet aluminum dust cap ready for installation right out of the box.

Features & Benefits

FOX 2.5 performance elite series shocks offer next level performance and damper capacity. Aluminium body for faster heat dispersion and DSC adjustable reservoir.
Performance UCAs increase strength and allow for more suspension travel
High strength cast torsion bar keys use an indexed design to provide additional ride height.
Sway bar relocation for proper clearance
Differential relocation to improve CV operating angle.
Rear block and u-bolt kit provides lift while maintaining spring function and load capacity.
Recommended Tires & Wheels

We do not recommend the factory wheels, as they hit the control arms. (Minimum offset we recommend is +18)
37" Tyres can be fitted with some trimming we recommend offsets between +18 +12 and zero, once you go negative more trimming is required.
35 x 12.5 with 20 x 9 and 5.75 in. Backspace.
295 / 60 with 20 x 9 and 5.75 in. Backspace
285 / 65 with 20 x 9 and 6.18 in. Backspace
