Offroad Industries BDS 4" Lift Kit FOX 2.5 Performance Elite Coilover Chevrolet Silverado 1500 (19-26)

BDS 4" SUSPENSION FOX 2.5 CHEVY SILVERADO 1500
Transform your 2019-2026 Chevy Silverado 1500 LTZ and ZR2 Trailboss with the BDS 4" Lift Kit featuring FOX 2.5 DSC coil-overs. This American-made suspension upgrade delivers a smoother, more controlled ride whether you're tackling rough terrain or cruising the highway. The advanced FOX damping system keeps your truck planted and responsive, while the extra 4 inches of lift opens up new possibilities for bigger tyres and aggressive styling. Built tough for trucks that demand more from their suspension.

Up the ante in performance with your Chevy Silverado and GMC Sierra 1500 truck by installing the BDS 4-inch lift kit suspension featuring FOX 2.5 Performance Elite coil-over shocks. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 33" tires. These kits feature proprietary FOX 2.5 coil-over shocks designed specifically to bolt-on performance for increase travel and the ability to soak up the roughest terrain along with smooth on-road comfort.

This kit takes advantage of BDS's tried and true high-clearance design for improved ground clearance, strength, and offroad protection while correcting suspension and steering geometry for great on-road handling characteristics. Up front, the kit utilizes FOX 2.5 Performance Elite coil-over shocks, high-arched 1/4-inch thick steel crossmembers along with a multipiece differential relocation brackets and heavy duty skid plates built for offroad protection. Steering geometry is corrected at the new taller ride height with CNC-machined ductile iron steering knuckles and replacement tie rod ends allowing for ESC system compatibility. These combined with the provided sway bar drops, bump stop extensions, brake line brackets, CV spacers, supplied hardware and more provide a comprehensive front suspension lift ready for whatever you throw at it.

In the rear BDS offers a heavy duty lift block to lift and level that stance. The lift block installs in place of the stock block and retains ride quality and load capacity. Also for the rear are new u-bolts, brake line brackets and precision tuned premium FOX 2.0 Performance Series shocks.

FOX PERFORMANCE ELITE SUSPENSION
FOX 2.5 Performance Elite shocks offer next level performance for on-road comfort and off-road comfort capability. Tuned and ready to install right out of the box, these bolt-on 2.5-inch diameter shocks are built for abuse and packed with race-proven technology. They include a remote reservoir for additional fluid capacity to keep your shocks running cool so you can push the limits in the rough terrain. The DSC adjuster adds remarkable versatility and precise tuning with a simple twist of either two adjuster knobs, offering 10 separate low-speed and 12 high-speed compression levels, with a black anodized aluminum reservoir to increase cooling efficiency.

HIGH CLEARANCE CROSSMEMBERS
BDS maximizes ground clearance with their heavy duty 1/4-inch thick laser cut perfect fit crossmembers. Paired with a front skid plate system that bolts together to create a rigid subframe while adding extra protection.

HEAVY DUTY STEERING KNUCKLES
BDS corrects steering geometry at the new taller ride height using a pair of high-strength, CNC machined ductile cast iron steering knuckle design to work with replacement tie rod ends to maintain steering angles for proper function and ESC compatibility.

Features & Benefits

FOX 2.5 Performance Elite series coilovers with DSC Adjuster for improved ride quality, performance, and capability
High clearance crossmember design maximizes ground clearance
Robust steering knuckles maintain ESC system compliance
High-strength replacement upper control arms provide durability and serviceability
HD skid plate system improved offroad protection
Multipoint differential relocation brackets to secure the front axle and improve CV angles
Factory Protection Plus drivetrain warranty included
RECOMMENDED TIRES & WHEELS
33 x 12.5 with 20 x 9 and 6.25 in. Backspace
35 x 12.5 with 20 x 9 and 6.25 in. Backspace
VEHICLE SUITABILITY
Chevy Silverado LTZ 2019 - 2024
Chevy Silverado Trail boss and ZR2 * Provides 2" of additional lift.

FOX 2.5 PERFORMANCE ELITE SERIES
Increased off-road capabilities
Easily adjust your shock for terrain, load and speed
2.5-inch Impact extruded aluminum body
Massive 7/8-inch hard chrome plated heat-treated alloy steel shaft
External reservoir design separates shock oil from the high-pressure nitrogen
DSC - Dual Speed Compression Adjuster comes standard
Fully serviceable for a lifetime of use
1-year Manufacturer's Warranty
